Summerset RFR-24WD 24" Dual Zone Outdoor Wine Cooler
CONTACT US FOR PRICE MATCH OR PRICE BEAT!
Two Temperature Zones, 46 Bottles, One 24-Inch Island Slot — Whites Chilled, Reds Ready, All at Once
The Summerset RFR-24WD is a UL-certified outdoor-rated dual-zone wine cooler with full 46-bottle capacity — keep white wines at 41–50°F and reds at 50–64°F simultaneously, in a single 24-inch built-in appliance.
The Summerset RFR-24WD 24-Inch Outdoor Rated Dual Zone Wine Cooler is the flagship of Summerset's outdoor wine cooler lineup — combining the full 46-bottle, 5.3 cubic foot capacity of the single-zone RFR-24W with two independently controlled cooling zones that let you hold whites at 41–50°F in the upper chamber and reds at 50–64°F in the lower, simultaneously, without ever moving a bottle. The anti-vibration forced-air compressor with R-134a refrigerant protects sediment and maintains precise temperatures across both zones. A tinted locking glass door provides UV protection and security, front venting enables true built-in installation in a standard 24-inch island opening, and digital front-panel controls give you independent setpoint management for each zone. 304 stainless exterior, UL-certified outdoor use, commercial grade, automatic defrost, adjustable leveling legs. The complete outdoor wine station in one slot.
What Makes the RFR-24WD the Top of the Summerset Wine Cooler Lineup
The RFR-24WD delivers everything the single-zone RFR-24W offers — same capacity, same footprint, same build quality — and adds the one feature that changes how you entertain: two independent temperature zones so every bottle is at the right temperature when the guest reaches for it.
Two Independent Temperatures — One Unit, Full Capacity
The upper zone holds 41–50°F for whites, rosés, and sparkling. The lower zone holds 50–64°F for reds that need cellar temperature. Both are independently controlled via the front digital panel — set each zone once and serve confidently at the right temperature every time, without having to move bottles between a separate white wine cooler and red wine storage.
Full Capacity — No Bottle Count Penalty for the Second Zone
Five wooden racks across 5.3 cubic feet hold up to 46 standard 750 ml bottles — the same count as the single-zone RFR-24W. Unlike the 15-inch dual-zone model which trades 8 bottles for the second zone, the 24-inch cabinet maintains full capacity across both zones. Stock a complete range of whites in the upper zone and reds in the lower without any storage compromise.
UL-Certified + Commercial Grade — Built for Demanding Environments
UL outdoor certification confirms independent safety approval for permanent outdoor installation in temperature extremes, humidity, and UV exposure. Summerset also designates the RFR-24WD as commercial grade — appropriate for resort, hospitality, and commercial outdoor kitchen applications alongside residential builds.
Anti-Vibration Compressor — Storage-Grade Protection for Both Zones
The forced-air compressor with R-134a refrigerant and anti-vibration design keeps both zones at their set temperatures without disturbing sediment in stored bottles — the distinction between a cooler that can hold a collection over weeks or months and one that's only suitable for chilling bottles you're opening tonight.
Tinted Glass Door with Factory Lock — UV Protection and Security
The tinted glass door reduces UV light transmission to the interior, protecting wine quality and labels from the sunlight exposure that's more significant in an outdoor setting than indoors. The factory-installed lock secures the collection in shared outdoor entertaining environments — no separate hardware required.
Front-Venting — True Built-In Without Rear or Side Clearance
Heat exhausts from the front of the unit, enabling full enclosure in a standard 24-inch outdoor kitchen island opening without clearance gaps at the sides or rear. The same front-venting design enables freestanding use on an open patio surface — a genuinely flexible installation option in a single appliance.
RFR-24W vs. RFR-24WD — The One Decision to Make
Everything about these two units is identical: same 24-inch footprint, same 5.3 cu. ft. capacity, same 46-bottle count, same 304 stainless exterior, same right-hinge tinted locking glass door, same cutout dimensions, same electrical, same weight, same warranty. The only difference is cooling configuration. The RFR-24W is single-zone — one temperature for the full cabinet, set anywhere from 41–64°F. The RFR-24WD is dual-zone — upper chamber independently held at 41–50°F, lower chamber at 50–64°F, simultaneously. If you serve both red and white wine and want both at the right temperature when guests arrive without moving bottles, choose the RFR-24WD. If your collection is primarily one style or you want complete single-setpoint flexibility, choose the RFR-24W.
Auto-Defrost and Control Lock — Runs Reliably Unattended
The RFR-24WD defrosts automatically — the compressor pauses on a set cycle while the fan continues running, preventing frost buildup in either zone without manual intervention. The front-panel control lock prevents accidental temperature adjustments during a gathering. These features make the RFR-24WD a set-and-leave appliance that maintains both zones precisely without monitoring — which is exactly what an outdoor dual-zone wine cooler needs to be in a busy entertaining environment.
Who the Summerset RFR-24WD Is For
- Outdoor entertainers who regularly serve both red and white wine — two independent zones mean both styles are at exactly the right serving temperature the moment guests arrive, without any last-minute bottle shuffling or trips inside.
- Buyers who want maximum capacity without sacrificing zone flexibility — unlike the 15-inch dual-zone which trades 8 bottles for the second zone, the RFR-24WD maintains full 46-bottle capacity with both zones active.
- Islands with a 24-inch appliance opening where wine is a central feature — the RFR-24WD anchors a dedicated outdoor wine and bar station with the capacity and dual-zone capability that a 15-inch slot cooler can't match.
- Commercial, resort, and hospitality outdoor kitchen installations — the commercial-grade designation and UL outdoor certification make this a legitimate specification for professional outdoor kitchen environments.
- Wine collectors who store bottles outdoors — the anti-vibration R-134a compressor and UV-reducing tinted door make this viable for medium-term wine storage, not just pre-service chilling.
- Anyone choosing between this and the RFR-24W who serves mixed collections — with identical capacity and footprint, the dual-zone version is the clear upgrade whenever both red and white feature regularly in your outdoor entertaining.
What's Included
Wine Cooler
- Summerset RFR-24WD dual-zone outdoor wine cooler
- Dual independent cooling zones (upper 41–50°F / lower 50–64°F)
- Anti-vibration forced-air compressor (R-134a refrigerant)
- Five wooden racks (46-bottle capacity, removable)
- Tinted glass door with factory-installed lock (right hinge)
- Digital front-panel dual-zone temperature controller with LED display
- Interior LED lighting
- Automatic defrost
- Adjustable leveling legs
Sold Separately
- Trim/Surround for Summerset 24-Inch Series Fridges — finishes the installation when built into an island opening
Summerset RFR-24WD Specifications
General
| Brand | Summerset Grills |
|---|---|
| Model | RFR-24WD (also listed as SSRFR-24WD) |
| Construction | 304 Stainless Steel exterior; tinted locking glass door |
| Outdoor Rated | Yes — UL Certified for outdoor use |
Cooling & Performance
| Temperature Zones | Dual — independently controlled |
|---|---|
| Upper Zone Range | 41–50°F (for white wine, rosé, and sparkling) |
| Lower Zone Range | 50–64°F (for red wine and cellar storage) |
| Cooling System | Compressor / forced air (R-134a refrigerant), anti-vibration |
| Defrost | Automatic |
| Controls | Front-panel digital dual-zone controller with LED display; control lock function |
Capacity & Interior
| Bottle Capacity | Up to 46 standard 750 ml bottles |
|---|---|
| Total Capacity | 5.3 cu. ft. |
| Racks | 5 wooden racks (removable) |
| Interior Lighting | LED |
| Door | Tinted glass; factory-installed lock; right hinge; straight towel bar handle |
Electrical & Installation
| Voltage / Amps | 120V / 15A |
|---|---|
| Venting | Front-venting (true built-in compatible; no rear or side clearance required) |
| Leveling | Adjustable leveling legs (included) |
| Hinge | Right hinge |
Dimensions & Weight
| Overall Dimensions (W × H × D) | 23.4" × 32.3" × 22.8" (59.4 × 82 × 57.9 cm) |
|---|---|
| Cutout Dimensions (W × H × D) | 24⅛" × 32¾" × 24" (61.3 × 83.2 × 61 cm) |
| Weight | 95 lb (43.1 kg) |
Warranty & Buyer Assurance
- Manufacturer's Warranty — Covered by Summerset's Gold Standard Warranty, honored directly by Summerset. For the RFR-24WD, this includes: Gold Standard Lifetime Warranty on stainless steel parts, doors, and drawers; one (1) year warranty on all construction and electrical components including the compressor, transformer, LED bulbs, LED harness, power source wire, LED switches, and interior lighting. Labor is not included. Warranty must be registered online within 30 days of purchase with proof of purchase and photo documentation. Valid for the original purchaser at the original delivery site only; void upon transfer of ownership. Does not cover commercial, rental, or nonresidential installations unless proper maintenance has been maintained, misuse, lack of regular cleaning, or damage from harsh environments.
- Free Shipping on orders over $100 to the contiguous 48 states.
- 45-Day Returns — Deck & Den's 45-day return window gives you time to confirm the RFR-24WD fits your installation before you commit.
- Price Match Available — found a lower authorized-dealer price? Contact us and we'll match it.
Manuals & Documents
- RFR-24WD User Manual (PDF) — installation, operation, and maintenance guide (covers RFR-15W, RFR-15WD, RFR-24W, and RFR-24WD).
- RFR-24WD Line Drawing (PDF) — engineering line drawing with full dimensional and cutout reference.
- RFR-24WD Cutout Dimensions Sheet (PDF) — cutout and clearance dimensions for island planning and contractor reference.
Summerset RFR-24WD — Frequently Asked Questions
What are the cutout dimensions for the RFR-24WD?
The required cutout for built-in installation is 24⅛" wide × 32¾" high × 24" deep — identical to the RFR-24W since both units share the same outer body. The cutout is slightly larger than the unit itself (23.4" × 32.3" × 22.8") to allow for installation clearance. Download the Line Drawing and Cutout Dimensions Sheet above for contractor-ready reference.
What temperatures do the two zones reach?
The upper zone is independently controlled from 41–50°F — ideal for white wines, rosés, and sparkling that should be served well-chilled. The lower zone is independently controlled from 50–64°F — appropriate for red wines at cellar temperature. Both zones maintain their respective setpoints simultaneously via separate controls on the front digital panel.
What is the difference between the RFR-24WD and the RFR-24W?
Both are 24-inch outdoor wine coolers with identical dimensions, capacity (46 bottles), racks (5 wooden), weight (95 lbs), cutout, electrical, UL certification, tinted locking glass door, right hinge, and warranty. The only difference is cooling configuration. The RFR-24W is single-zone (41–64°F, full cabinet at one setpoint). The RFR-24WD is dual-zone (upper 41–50°F / lower 50–64°F, independently controlled). Choose the RFR-24WD if you regularly serve both red and white wine; choose the RFR-24W for single-setpoint flexibility or a predominantly one-style collection.
Does the dual-zone model hold fewer bottles than the single-zone?
No — both the RFR-24WD and RFR-24W hold up to 46 standard 750 ml bottles across five wooden racks. Unlike the 15-inch models where the dual-zone divider reduces bottle count from 28 to 20, the 24-inch cabinet maintains full capacity with both zones active. The choice between single-zone and dual-zone at this size is purely about temperature flexibility, with no storage compromise.
Can this be installed as a true built-in?
Yes — front-venting design allows full enclosure in a 24-inch island opening without rear or side clearance gaps. It can also be used freestanding. When built in, the Summerset trim/surround for 24-inch series fridges is available separately to finish the installation cleanly.
Is the RFR-24WD UL-certified for outdoor use?
Yes — independently UL-certified for permanent outdoor installation. The unit has been tested and approved for the temperature extremes, humidity, and UV exposure of an outdoor environment. Indoor wine coolers placed outdoors are not built for these conditions and typically void their warranty in outdoor use. The RFR-24WD is also designated commercial grade by Summerset, making it appropriate for resort, hospitality, and professional outdoor kitchen installations.
What electrical connection does the RFR-24WD require?
The RFR-24WD runs on 120V / 15A — a standard household circuit on a grounded 3-prong connection. Confirm your island electrical plan with an electrician before installation to ensure adequate circuit capacity for all appliances in the layout.
How many racks does the RFR-24WD have, and are they removable?
The RFR-24WD has five wooden racks distributed across the two zones. They are removable — the user manual instructs you to tape them in place during transport to prevent movement, confirming they can be taken out. The wooden rack design holds standard 750 ml bottles without vibration contact with metal shelving.
What is Summerset's warranty on the RFR-24WD?
The RFR-24WD is covered by Summerset's Gold Standard Warranty: Lifetime on stainless steel construction, doors, and drawers; one (1) year on all construction and electrical components including the compressor, transformer, LED bulbs, wiring, switches, and interior lighting. Labor is not included. Register within 30 days of purchase with proof of purchase and photo documentation; valid for the original purchaser at the original delivery site only.
What shipping and return policies apply at Deck & Den?
Deck & Den offers free shipping on orders over $100 to the contiguous 48 states. The RFR-24WD is covered by Deck & Den's 45-day return policy. Price matching is available — contact us with a qualifying authorized-dealer price and we'll match it.
